Price:
$269
*Check with our team or your local store for availability.
We guarantee that all of our stock is 100% genuine, with full local warranty.
Colour: Black

Description

  • 2×300W output at 4Ω
  • Texas Instruments TPA3255 amplifier platform
  • Bluetooth 6.0 with SBC, AAC, and LDAC support
  • USB, coaxial, and line inputs
  • Speaker, subwoofer, and pre-out connections
  • Independent bass and treble controls
  • RGB input and codec indicator lighting
  • Aluminum and wood chassis construction
  • External 48V/5A power supply included
FiiO Jade Audio LEVEL 1 High-Res Audio Power Amplifier Specifications
Amplifier Chip Texas Instruments TPA3255
Bluetooth Chip Zhongke Lanxun BT8961
Bluetooth Version 6.0
Colors Black (Walnut Wood) / Silver (Maple Wood)
Construction Materials Aluminum Alloy Chassis with Solid Wood Side Panels
Dimensions 18.1 cm × 13.3 cm × 3.6 cm (excluding feet)
Input Power DC 24–53 V
Inputs LINE IN / USB IN / COAX IN / Bluetooth
Outputs SPEAKERS OUT / SW OUT / PRE OUT
Weight 676 g
Coaxial Input PCM up to 24-bit / 192 kHz
Supported Bluetooth Codecs SBC / LDAC
USB Input PCM up to 24-bit / 96 kHz
Distortion ≤ 0.05%
Dynamic Range ≥ 99 dB
Frequency Response 20 Hz – 40 kHz
Signal-to-Noise Ratio ≥ 105 dB
Output Power (48V/5A PSU) Max L+R ≥ 120 W + 120 W @ 4 Ω (THD+N < 1%)
Max L+R ≥ 115 W + 115 W @ 8 Ω (THD+N < 1%)
Output Power (53V/12A PSU) Max L+R ≥ 300 W + 300 W @ 4 Ω (THD+N < 10%)
Max L+R ≥ 190 W + 190 W @ 8 Ω (THD+N < 10%)
  • 1 x Jade Audio Level 1
  • 1 x AC Power Cord
  • 1 x 48V 5A Power Adapter
  • 1 x Warranty Card
  • 1 x Quick Start Guide
