| Pilium Kratos Mono Amplifier Specifications | |||
| Design | Dedicated unique mono design | ||
| Power Output | 1 × 400 W @ 8Ω 1 × 800 W @ 4Ω 1 × 1600 W @ 2Ω (0.5Ω stable) |
||
| Frequency Response (–3 dB) | 0.1 Hz – 125 kHz | ||
| Signal-to-Noise Ratio | -133.2 dB | ||
| Total Harmonic Distortion (THD+N) | 0.00260% @ 1 kHz, 50 W | ||
| Voltage Gain | +31 dB (35) | ||
| Analog Input | 1 × XLR (Vin = 1.8 VRms, Zin = 5 kΩ) | ||
| Output Impedance | < 0.1 Ω | ||
| Power Consumption (Standby) | 68 W | ||
| Power Consumption (Maximum) | 3100 W | ||
| Signal Input | 1 × XLR | ||
| Speaker Terminals | 2 pairs | ||
| Ground Input | 1 × Binding post | ||
| Power Inputs | 1 × IEC 16A + 1 × IEC 10A | ||
| Dimensions (H × W × D) | 412 × 480 × 605 mm | ||
| Net Weight | 154 kg | ||
| Shipping Weight | 182 kg | ||
